The ATHENA is the ultimate router for the multi-device household. Built with a 1.4GHz Qualcomm® Dual Core Processor, 16 high power amplifiers, and 4 high gain antennas, the ATHENA delivers unmatched Wi-Fi performance. It is equipped to provide unprecedented coverage, speed, and reliability for the most demanding networks with many connected devices. Extremely fast AC2600 Wi-Fi technology provides up to 2.53Gbps, making lag and buffering a thing of the past for everyone.3 The ATHENA also features cutting edge MU-MIMO technology that enables multiple devices to receive data at once, granting uninterrupted streaming for all.2
How does MU-MIMO Technology work? Say you have a traditional network with 3 devices and they are all downloading data at the same time. Device 2 will have to wait for Device 1 to finish receiving data from the router before it can receive its own data, then Device 3 must wait until Device 2 gets data before it will receive its data. The ATHENA with MU-MIMO, on the other hand, will allow all 3 devices to receive data at once. This means increased Wi-Fi speeds and overall better performance for all connecting devices.2
Maximum Wi-Fi Range
High Power Wi-Fi for whole home or whole office coverage
16 Powerful Amplifiers & 4 Antennas
Amplify Wi-Fi to the max with advanced amplifiers and 4 antennas
Multi User MIMO
Deliver data to multiple devices at once for a boost in performance and up to 3X more speed2
Unmatched AC2600 Wi-Fi Speeds
Move faster than ever with speeds up to 2.53Gbps: 2.4GHz 800Mbps + 5GHz 1733Mbps3
4 Simultaneous Wi-Fi Streams
Delivers the fastest speeds for maximum performance and connection reliability
High Power Qualcomm® Processor
A 1.4GHz dual core processor handles heavy traffic with ease, for the best Wi-Fi experience
Advanced Security Features
Adjust the coverage of your network, block websites and utilize SPI Firewall
Beamforming Technology
Strengthen Wi-Fi connections with focused Wi-Fi streams for each connected device
Ultimate Gaming, HD & 4K
Seamlessly stream HD and 4K content to multiple devices and eliminate gaming lag
Bandwidth Optimization
Prioritize bandwidth for specific applications, networks and devices on your network
Share Files with USB
Attach a USB drive and instantly share files at blazing-fast speeds, locally or remotely*
Specifications are subject to change without notice.
1 Range specifications are based on performance test results. Actual performance may vary due to differences in operating environments, building materials and wireless obstructions. Performance may increase or decrease over the stated specification. Wireless coverage claims are used only as a reference and are not guaranteed as each wireless network is uniquely different. Maximum wireless signal rate derived from IEEE 802.11 standard specifications. Actual data throughput may vary as a result of network conditions and environmental factors. Output power specifications are based on the maximum possible radio output power plus antenna gain. May not work with non-standard Wi-Fi devices such as those with proprietary software or drivers. Supports all Wi-Fi standards that are compatible or backwards compatible with 802.11a/b/g/n/ac Wi-Fi standards. 2 For MU-MIMO to work, additional MU-MIMO capable devices must be connected to the network. To achieve the "up to 3X" data rate increase, three or more 1x1 MU-MIMO devices are needed with optimal network environment conditions.
3 All transmission rates listed, for example 800Mbps for 2.4GHz and 1733Mbps for 5GHz, are the physical data rates. Actual data throughput will be lower and may depend on external factors as well as the combination of devices connected to the router. AC2600 wireless speeds are achieved when connecting to other AC2600 capable devices.
Wi-Fi, Wi-Fi Protected Setup, and WPA2 are either registered trademarks or trademarks of the Wi-Fi Alliance. Qualcomm is a trademark of QUALCOMM Incorporated, registered in the United States and other countries. Qualcomm MU|EFX and Qualcomm Internet Processor (IPQ) are products of Qualcomm Atheros, Inc.
Make sure your computer is connected to the Router using the included Ethernet cable. Do not try to connect with a wireless connection. Ensure that the power on the Router is on.
Check that your computer IS NOT connected to any wireless networks. If it is, disable your Wi-Fi connection and disconnect from all wireless networks. Reboot the router and try again.
Close your current web browser and reopen it. Use Google Chrome or Internet Explorer (v8.0 and up).
Open your web browser and enter 192.168.3.1 into the web address bar.
If you can access the web menu, but not the Setup Wizard, the Router may have previously been configured. There is a link to re-access the Setup Wizard from the Dashboard. Scroll to the bottom of the Dashboard page to find the Setup Wizard link.
Another way to access the Setup Wizard is to reset the Router to default settings by holding the Reset Button (located on the back panel) for ten (10) seconds and try again. The Setup Wizard will always appear if the Router has not yet been configured. After it has been configured the Dashboard will appear instead.
Make sure your computer is connected to the Router using the included Ethernet cable. Do not try to connect with a wireless connection. Ensure that the power on the Router is on.
Check that your computer IS NOT connected to any wireless networks. If it is, disable your Wi-Fi connection and disconnect from all wireless networks. Reboot the router and try again.
Close your current web browser and reopen it. Use Google Chrome or Internet Explorer (v8.0 and up).
Open your web browser and enter 192.168.3.1 into the web address bar.
If the Setup Wizard appears instead of the Dashboard, the Router has not yet been configured. Complete the Setup Wizard or skip the Setup Wizard to access the Dashboard.
Reset the Router to default settings by holding the Reset Button (located on the back panel) for ten (10) seconds and try again. Complete the Setup Wizard or skip the Setup Wizard to access the Dashboard.
Check that you are using a supported web browser: Google Chrome, Internet Explorer (8.0 and up) and Safari. If you are using an unsupported web browser, such as Firefox, please change to one of the supported web browsers and try again.
Reset your modem by holding down the reset button located on the back of the modem for approximately five seconds. Try the automatic configuration again.
Static IP: Your Internet connection may require a static IP setting. Check with your ISP to obtain the IP settings.
DSL Connections: Your Internet connection may require login information. If you are using PPPoE mode, you will need to manually configure your Internet connection settings and obtain your username and password.
Cable Modem: Your Internet connection may require you to clone your MAC address. Go to More Settings > IP Settings > Internet Network (WAN) and select Automatic/Dynamic (DHCP) from the drop down menu. Clone your PC's MAC address under the DNS settings.
Detach the power adapter and disconnect all computers from the Router. Turn off the power to your modem and remove the backup battery (if available). Wait 2 minutes and power the modem back on. Wait 2 minutes for the modem to initialize. Power on the Router and connect your computer to the router. Open your web browser and try to access the Internet.
Check that your Internet connection through the modem is working. Power off the Router and disconnect your computer from the router. Turn off the power to your modem and remove the backup battery (if available). Wait 2 minutes and power the modem back on. Wait 2 minutes for the modem to initialize. Attach your computer directly to the modem and power on your computer. Open your web browser and check to see if you can go online. If you cannot go online, there may be a problem with your Internet provider. Please contact your Internet provider to troubleshoot your connection issues.
Power off your computer, the Router and your modem. Power on your modem and wait 2 minutes. Power on the Router and wait 1 minute for the router to initialize. Power on your computer and try again.
Check to see if other computers are also having this problem. If they are not, check to see if your antivirus software or firewall software is conflicting with your Internet connection. You may also try temporarily disabling all firewalls or antivirus software to see if that is what is causing the problem.
If you have a PPPoE or another Internet connection requiring login credentials, you may need to adjust the reconnection or time out settings. Go to the IP Settings > Internet Connection (WAN) page and configure your Internet connection to automatically reconnect.
If you are using Windows XP, check that your computer is using Service Pack 2 or greater. Windows XP users with Service Pack 1 may experience intermittent wireless connections.
Check with your Internet provider to ensure that they are not experiencing system wide issues.
Check with speedtest.net to see the speed of your Internet provider. Connect directly to your modem with your computer and check speedtest.net again. If the speed results are the same, the issue is with your Internet provider. Please contact your provider to troubleshoot the issue.
Check the Internet connection speed on another computer that is connected to the Router. If the other computer does not have Internet speed problems, the networking equipment or operating system on your original computer may be outdated or may be experiencing problems. Viruses and other software may slow down a computer’s overall speed significantly.
If you are using a wireless connection to the Router, check that your wireless signal strength is above 3 bars. If not, you may need to move closer to the Router.
Step back at least 10 feet from the Router and check your signal again. The Router emits high power, long range Wi-Fi signals that may confuse your wireless adapter signal reading at close range. The speed and signal are at 100%, however your readout may not be displaying the data correctly.
Change the wireless channel on your Router to find a channel with less interference. Do this for both 2.4GHz and 5.0GHz wireless networks. To assist in finding the right channel, download the Amped Wireless Wi-Fi Analytics Tool for your Android or PC.
Check that your antennas are securely fastened to the Router.
Check if other computers are experiencing the same issue. If not, the wireless adapter in your computer may be experiencing problems or may be older and have poor wireless performance.
Avoid placing the Router near or around Microwaves and 2.4GHz wireless phones.
Avoid using wireless channels that are crowded. Change the wireless channel on the Router.
Place the Router in a higher location near the center of your desired coverage location.
Position the antennas on the Router in opposite orientations.
Your wireless network adapter may be outdated and have older wireless technology not capable of achieving the wireless network speeds of the Router. To achieve maximum wireless speeds, it is required that you have a 802.11n (2.4GHz) or 802.11ac (5.0GHz) adapter. To obtain a data rate of 1733Mbps on the 5GHz band or 800Mbps on the 2.4GHz band the network adapter used to connect to the Router must support the same data rates.
Check that you are using the latest Wi-Fi security type: WPA or WPA2. WEP security may slow down your wireless speeds.
Check that the Router’s wireless data rate is set to AUTO or 11N (2.4GHz) and 11AC (5.0GHz) data rate speeds.
Wireless speeds degrade as you get further away from the wireless router.
Check that the wireless channel set on the Router is not crowded. Try changing the wireless channel to another channel and test the speed again.
Do not use Internet websites (i.e. speedtest.net or other websites) to test your wireless speeds. Speed test websites measure your Internet connection speed, which is controlled by your Internet provider. Wireless speeds are for your local network and not your Internet connection. To test wireless speeds, a local test or file transfer will be required to test the true wireless speed.
Check that the connected devices support MU-MIMO technology. All connected devices must also support MU-MIMO to enable the MU-MIMO function. If the connected device does not support MU-MIMO it will function as a SU-MIMO (single-user MIMO) device.
Make sure your computer has the latest Windows Service Pack. Windows Service Pack 1 does not support WPA security. Upgrade to the latest Service Pack to support the latest wireless encryption.
Manually add a wireless network to your XP computer.
Insert a USB storage device, such as a flash drive or external hard drive, to the USB port on the back of the Router.
From the USB Storage/FTP Server page of the web menu, enter a FTP server name.
Select whether you wish to have an open or secured access to your FTP server.
Open your FTP client software (not provided) and create a new FTP connection. To find a FTP client software, go to downloads.com and search for FTP client software. Download a FTP software suitable for your needs and continue with the next step.
Enter the Internet Address for the router as the IP address for your FTP connection. When prompted enter your login information to access the USB Storage device remotely.
Remove the USB storage device from the Router and reboot it by unplugging the power adapter. Once rebooted, try inserting the USB storage device again.
Make sure your UBS storage device is not corrupted and is working properly and try again.
Ultimate Range & Wi-Fi Coverage Add long range Wi-Fi to your entire home or office with the ATHENA. High Power amplifiers, low noise amplifiers and high gain antennas provide the ultimate Wi-Fi experience with a signal that easily penetrates walls and eliminates Wi-Fi dead spots.
16 Powerful Amplifiers & 4 Antennas The ATHENA is packed with the latest high power technology. With a total of 16 advanced amplifiers (4 x 2.4GHz amplifiers, 4 x 5GHz amplifiers, 4 x 2.4GHz signal reception amplifiers, 4 x 5GHz signal reception amplifiers) and 4 high gain 5dBi antennas, it delivers up to 800mW of output power. Providing the ultimate Wi-Fi performance and coverage, it is a leader in its class.
Multi-User MIMO by Qualcomm® MU|EFX – More Streaming for Everyone Standard routers send data to one device at a time. The ATHENA router with MU-MIMO technology delivers up to 3X the speed by serving data to multiple devices at once for uninterrupted and blazing-fast movie streaming, gaming and downloading for everyone at the same time.2
Unmatched AC2600 Wi-Fi for Flawless HD & 4K Streaming Move faster than ever with unprecedented Wi-Fi speeds of up to 2.53Gbps, that's 800Mbps on the 2.4GHz frequency and 1733Mbps on the 5GHz. Seamlessly stream HD and 4K content to multiple devices at once and eliminate gaming lag.3
More Bandwidth for More Devices The ATHENA combines AC2600 Wi-Fi speeds with Amped Wireless' High Power Technology to provide multiple room, blazing-fast Wi-Fi coverage. The increased bandwidth of AC2600 with MU-MIMO Wi-Fi means your entire family can stream whatever they want, whenever they want, with no lag, all at the same time.
Parental Security Features & Guest Networks You're in control! Smart security features allow you to set the exact days and times that the networks are available, control the strength of your signal, and even block specific devices from accessing the network at all. Create up to 8 additional Wi-Fi networks for guests or conference rooms and enjoy secure connections with WPS push button configuration.
High Power Dual Core Qualcomm® Internet Processor Do more now with a powerful 1.4GHz dual core processor that is built to handle heavy traffic with ease, for the best networking experience.
Beamforming Technology for More Reliable Wi-Fi Connections Beamforming Technology strengthens Wi-Fi connections with focused Wi-Fi streams for each connected device. This results in fewer dropped signals for more reliable and stable connections.
Bandwidth Optimization to Prioritize Your Network Traffic Prioritize bandwidth for specific applications, networks, and devices on your network to optimize network bandwidth for streaming devices.
Share Files Faster with USB 3.0 Includes two USB ports, one USB 3.0 and one USB 2.0. These ports are designed for attaching USB storage devices, such as an external hard drive or flash drive, to share at home or in the office with other networked computers. Shared files can also be access remotely, over the Internet using a FTP client.
Simple Setup The Basic Setup Wizard walks you through the simple setup process and automatically configures the settings of your Internet provider. Taking only minutes, your new High Power Wi-Fi network will be up and running in no time.
Specifications are subject to change without notice.
1 Range specifications are based on performance test results. Actual performance may vary due to differences in operating environments, building materials and wireless obstructions. Performance may increase or decrease over the stated specification. Wireless coverage claims are used only as a reference and are not guaranteed as each wireless network is uniquely different. Maximum wireless signal rate derived from IEEE 802.11 standard specifications. Actual data throughput may vary as a result of network conditions and environmental factors. Output power specifications are based on the maximum possible radio output power plus antenna gain. May not work with non-standard Wi-Fi devices such as those with proprietary software or drivers. Supports all Wi-Fi standards that are compatible or backwards compatible with 802.11a/b/g/n/ac Wi-Fi standards. 2 For MU-MIMO to work, additional MU-MIMO capable devices must be connected to the network. To achieve the "up to 3X" data rate increase, three or more 1x1 MU-MIMO devices are needed with optimal network environment conditions.
3 All transmission rates listed, for example 800Mbps for 2.4GHz and 1733Mbps for 5GHz, are the physical data rates. Actual data throughput will be lower and may depend on external factors as well as the combination of devices connected to the router. AC2600 wireless speeds are achieved when connecting to other AC2600 capable devices.
Wi-Fi, Wi-Fi Protected Setup, and WPA2 are either registered trademarks or trademarks of the Wi-Fi Alliance. Qualcomm is a trademark of QUALCOMM Incorporated, registered in the United States and other countries. Qualcomm MU|EFX and Qualcomm Internet Processor (IPQ) are products of Qualcomm Atheros, Inc.
Ultimate Coverage, Maximum Streaming, More Devices
Browse the selections below to view support materials and troubleshooting tips. FAQs provide you with answers to frequently asked questions. The Download section provides you with firmware upgrades or device drivers and other related software. To view the User's Guide for your product check out the Documentation section. If you are having problems finding what you need, contact us.
Added Guest Network Internet and Local Access option
Added IPv6 Support
Added support for Firefox
Added SIP ALG support
Important: Before upgrading firmware, always save your current settings from the Save/Reload Settings page.
To access from the web menu: More Settings > Management > Save/Reload Settings > Save Settings to File After the firmware updates, load your saved settings to keep your existing configurations.
4 x 2.4GHz Amplifiers 4 x 5GHz Amplifiers 8 x Low Noise Amplifiers
Processor:
1.4GHz Dual Core Qualcomm® Processor
Memory:
128MB Flash, 512MB DDR3
Wireless Coverage Control:
15% - 100% Output Power (Individually adjustable for 2.4GHz and 5GHz networks)
Antennas:
4 x Detachable High Gain 5dBi Dual Band Antennas
Ports:
1 x RJ-45 10/100/1000M WAN Port (Modem Port) 4 x RJ-45 10/100/1000M LAN Ports (Local Ports) 1 x USB 2.0 Port for USB Storage 1 x USB 3.0 Port for USB Storage
Specifications are subject to change without notice.
Range specifications are based on performance test results. Actual performance may vary due to differences in operating environments, building materials and wireless obstructions. Performance may increase or decrease over the stated specification. Wireless coverage claims are used only as a reference and are not guaranteed as each wireless network is uniquely different. Maximum wireless signal rate derived from IEEE 802.11 standard specifications. Actual data throughput may vary as a result of network conditions and environmental factors. Output power specifications are based on the maximum possible radio output power plus antenna gain. May not work with non-standard Wi-Fi devices such as those with proprietary software or drivers. Supports all Wi-Fi standards that are compatible or backwards compatible with 802.11a/b/g/n/ac Wi-Fi standards.
For MU-MIMO to work, additional MU-MIMO capable devices must be connected to the network.
All transmission rates listed are the physical data rates. Actual data throughput will be lower and may depend on external factors as well as the combination of devices connected to the router. 802.11ac wireless speeds are achieved when connecting to other 802.11ac capable devices.
Wi-Fi, Wi-Fi Protected Setup, and WPA2 are either registered trademarks or trademarks of the Wi-Fi Alliance. Qualcomm is a trademark of QUALCOMM Incorporated, registered in the United States and other countries. Qualcomm MU|EFX and Qualcomm Internet Processor (IPQ) are products of Qualcomm Atheros, Inc.
